Ø S.S.304 construction including main machine frame.
Ø Built in product counter.
Ø “No Container –No Label” an electronic sensing device avoids wastage of labels.
Ø Machine is suitable for round container for wrap around labelling with the help of change parts.
Ø Easy to change label application height.
Ø Top Conveyor to holding product at the time of labelling.
Ø Built in A.C. Variable Frequency Drive System.
Ø Incompliance with GMP
Technical Specifications |
---|
Technical Specifications |
||
Machine Name |
One Head Label Applicator |
|
Model |
Servo Based Machine |
|
Production Speed Per Minute |
Up to 90 Products per Minute (Speed Depends on the Size of the Product and label length). |
|
Number of Labeling Dispenser |
1 Labeling Dispenser Head |
|
Suitable for Products |
Square and Rectangle Bottle |
|
Application |
Labeling on single side of container |
|
Labels Requirement |
Self-Adhesive Sticker Labels in Roll Form having consistent 3 mm gaps between the 2 labels. |
|
Label Material |
Self-Adhesive Cromo Paper Labels |
|
Label Roll Outer Diameter |
Maximum 300 mm |
|
Label Core ID |
75 mm |
|
Label Dispensing Accuracy |
+1 mm |
|
Container Holding Unit |
Belt Type Spring Based Top Conveyor. |
|
Working Height |
850 mm (+50 mm) |
|
Conveyor Length |
6 Feet |
|
Machine Weight |
Approx 350 Kgs |
|
Machine Dimension |
Approx 6 (L) x 7 (W) x 5 (H) – in Feet |
Technical Specifications |
||
Machine Name |
TwoHead(frontandback)Label Applicator |
|
Model |
Servo Based Machine |
|
Production Speed Per Minute |
Upto 90 Products per Minute(Speed Depends uponthe Size of the Product and label length). |
|
Number of Labeling Dispenser |
2Labeling Dispenser Head |
|
Suitable for Products |
Squareand Rectangle Bottle |
|
Application |
Labeling on double side of container |
|
Labels Requirement |
Self-Adhesive Sticker Labels in Roll Formhavingconsistence3mmgaps between the 2 labels. |
|
Label Material |
Self-AdhesiveCromo Paper Labels |
|
Label Roll Outer Diameter |
Maxi mum 300mm |
|
Label Core ID |
75mm |
|
Label Dispensing Accuracy |
+1mm |
|
Container Holding Unit |
Belt Type Spring Based Top Conveyor. |
|
Working Height |
850mm(+50mm) |
|
ConveyorLength |
6Feet |
|
Machine Weight |
Approx.350Kgs |
|
Machine Dimension |
Approx.6(L) x7(W) x 5(H) –in Feet |
