• Hydraulic mould clamping system to enhance power efficiency. It saves air consumption and hence reduces production cost.
• Unique mechanical lock system for positive locking.
• Close loop heating system and auto chamber temperature control (to compensate variation in preform heating due to ambient temperature).
• Optional auto preforms temperature control.
• Positioning of heaters is better, ensuring faster and simpler heating. Individual heater position is adjustable in both axes to achieve optimum heating.
• Air ventilation with controllable venting in heating chamber (for better heat penetration control).
• Start-stop index type oven to minimize variation in temperature of both preforms coming out of chamber at a time.
Technical Specifications |
---|
MODEL |
SSPI/SA/5/5000 |
|||
Max. Blowing Pressure |
30 kg/CM² |
|||
Locking Force |
25 Ton |
|||
Mould Thickness |
175 mm – 250 mm |
|||
Opening Stroke |
250 mm |
|||
Distance Between Tie Rods |
445 mm |
|||
Total Weight (Approx.) |
1500 Kg |
2000 Kg |
||
|
Two Cavity |
Single Cavity |
Two Cavity |
Single Cavity |
Production |
800-900 |
400 Jars/Hour |
450- 500 |
250-300 |
Max Neck Size |
53 mm |
120 mm |
53 mm |
120 mm |
Max Product Diameter |
130 mm |
200 mm |
130 mm |
200 mm |
Max Product Volume |
2 Liters |
5 Liters |
2 Liters |
|
Utility Requirements |
||||
Compressed Air |
|
|
||
System Air |
7 CFM |
4 CFM |
||
Blowing Air |
22 CFM for 1 Litre Water Bottle @ 800 BPH @30 kg/cm2 |
16 CFM for 1 Litre Water Bottle @ 500 BPH @30 |
||
Cooling Tower |
50 LPM @ 2 to 4 kg/10 TR |
50 LPM @ 2 to 4 kg/10 TR |
||
Chiller |
- |
3 TR |
||
Power – Total Connected Load (Without Utilities) |
||||
Heating Load |
9 KW |
24 KW |
||
Other Load |
3 KW |
4 KW |
||
Total Load |
12 KW |
28 KW |
||
|
415 VAC, 3 Phase 4 Wire + E,50 HZ |
|
