Swami Samarth's latest technologies in this rapid growth cycle meet the demand for superior parts quality long life - cycle of machineries, budget effective cost and prevision The electronic and telecommunication industries are highlight by rapid product development cycle. Swami Samarth always tries to matches the continuously evolving and innovating market and also help to keep our customer competitive in today global market. Swami Samarth offers you the latest and high - performance products to satisfy your requirement.
Technical Specifications |
---|
MODEL |
SSPI-60 |
SSPI-80 |
SSPI-100 |
SSPI-130 |
|||||||||
A |
B |
C |
A |
B |
C |
A |
B |
C |
A |
B |
C |
||
Screw Diameter |
mm | 25 | 30 | 35 | 32 | 35 | 38 | 35 | 38 | 42 | 38 | 42 | 45 |
Screw L/D ratio |
24 | 21 | 19 | 22 | 20.1 | 18.5 | 22 | 20.3 | 42 | 24 | 22 | 20.5 | |
Shot Size(Theoretical) | cm3 | 64 | 92 | 125 | 133 | 160 | 190 | 163 | 193.2 | 235 | 226 | 277 | 318 |
Injection Weight |
g | 56 | 80 | 109 | 121 | 146 | 173 | 148 | 176 | 214 | 206 | 252 | 289 |
Injection Pressure |
Mpa | 275 | 191 | 140 | 203 | 170 | 144 | 219 | 184 | 152 | 208 | 171 | 149 |
Screw Speed |
r/min | 224 | 0-225 | 0-210 | 0-185 | ||||||||
Clamp Tonnage |
KN | 600 | 800 | 1000 | 1300 | ||||||||
Toggle Stroke |
MM | 280 | 320 | 350 | 380 | ||||||||
Tia bar diameter |
MM | 55 | 60 | 65 | 75 | ||||||||
Space Between Tie Bars |
MM | 310x310 | 360x340 | 370x370 | 420x420 | ||||||||
Max.Mold Height |
MM | 330 | 350 | 380 | 450 | ||||||||
Max.Mold Height |
MM | 100 | 150 | 150 | 160 | ||||||||
Ejector Stroke |
MM | 80 | 90 | 120 | 140 | ||||||||
Ejector Tonnage |
KN | 30 | 30 | 38 | 50 | ||||||||
Max.Pump Pressure |
Mpa | 16 | 16 | 16 | 16 | ||||||||
Pump Motor Power |
KW | 7.5 | 11 | 13 | 13 | ||||||||
Heater Power |
KW | 5 | 6.5 | 7.5 | 8 | ||||||||
Machine Dim. (LxWXH) |
M | 3.6x1.12x1.72 | 3.9x1.2x1.8 | 4.3x1.3x2.0 | 4.6x1.5x2.1 | ||||||||
Machine Weight |
T | 2.5 | 2.8 | 3.4 | 4 |
MODEL |
SSPI-180 |
SSPI-200 |
SSPI-260 |
SSPI-300 |
|||||||||
|
A |
B |
C |
A |
B |
C |
A |
B |
C |
A |
B |
C |
|
Screw Diameter |
mm |
42 | 45 | 50 | 45 | 50 | 55 | 50 | 55 | 60 | 55 | 60 | 65 |
Screw L/D ratio |
23.6 | 22 | 19.8 | 24.4 | 22 | 20 | 24 | 22 | 20.3 | 24 | 22 | 20.3 | |
Shot Size(Theoretical) |
cm3 | 311 | 357 | 441 | 397 | 490 | 593 | 592 | 704 | 826 | 676 | 805 | 945 |
Injection Weight |
GMS | 283 | 325 | 402 | 362 | 446 | 540 | 539 | 641 | 752 | 615 | 733 | 860 |
Injection Pressure |
Mpa | 203 | 177 | 143 | 207 | 168 | 138 | 202.3 | 170 | 144.9 | 202.3 | 170 | 144.9 |
Screw Speed |
r/min | 0-180 | 0-155 | 220 | 220 | ||||||||
Clamp Tonnage |
KN | 1800 | 2000 | 2600 | 2900 | ||||||||
Toggle Stroke |
MM | 435 | 475 | 540 | 590 | ||||||||
Tia bar diameter |
MM | 80 | 90 | 95 | 100 | ||||||||
Space Between Tie Bars |
MM | 470x470 | 520x520 | 570x570 | 620x620 | ||||||||
Max.Mold Height |
MM | 500 | 550 | 600 | 630 | ||||||||
Max.Mold Height |
MM | 180 | 200 | 200 | 200 | ||||||||
Ejector Stroke |
MM | 140 | 150 | 150 | 150 | ||||||||
Ejector Tonnage |
KN | 50 | 70 | 70 | 70 | ||||||||
Ejector Number |
5 | 5 | 5 | 5 | |||||||||
Max.Pump Pressure |
Mpa | 16 | 16 | 16 | 16 | ||||||||
Pump Motor Power |
KW | 18.5 | 18.5 | 30 | 30 | ||||||||
Heater Power |
KW | 12.5 | 14 | 19 | 19 | ||||||||
Machine Dim. (LxWXH) |
M | 5.1x1.5x2.2 | 5.7x1.6x2.3 | 6.2x1.5x2.2 | 6.3x1.7x2.4 | ||||||||
Machine Weight |
T | 6 | 7 | 8.3 | 9.3 |
MODEL |
SSPI-350 |
SSPI-400 |
SSPI-500 |
SSPI-600 |
|||||||||
|
A |
B |
C |
A |
B |
C |
A |
B |
C |
A |
B |
C |
|
Screw Diameter |
mm | 70 |
75 |
80 |
75 |
80 |
85 |
80 |
85 |
90 |
90 |
95 |
100 |
Screw L/D ratio |
21.5 |
20 |
19 |
21.5 |
20 |
19 |
20.5 |
20 |
18.7 |
21 |
20 |
18.8 |
|
Shot Size(Theoretical) |
cm3 | 1283 |
1472 | 1666 | 1710 |
1945 |
2196 |
2180 |
2420 | 2650 |
2600 |
2950 |
3250 |
Injection Weight |
GMS | 1167 |
1339 | 1515 | 1555 |
1770 |
2000 |
1922 |
2170 | 2432 |
2432 |
2710 |
3003 |
Injection Pressure |
Mpa | 180 |
156 | 138 | 173 |
152 |
135 |
189 |
167 | 149 |
184 |
165 |
149 |
Screw Speed |
r/min | 155 |
150 |
150 |
125 |
||||||||
CLAMPING UNIT |
|||||||||||||
Clamp Tonnage |
KN | 3800 |
4000 |
5300 |
6200 |
||||||||
Toggle Stroke |
mm | 670 |
740 |
810 |
870 |
||||||||
Tia bar diameter |
mm | 115 |
130 |
135 |
155 |
||||||||
Space Between Tie Bars |
mm | 710x710 | 760x760 | 810x810 | 860x850 | ||||||||
Max.Mold Height |
mm | 750 |
800 |
850 |
920 |
||||||||
Min.Mold Height |
mm | 250 |
300 |
200 |
250 |
||||||||
Ejector Stroke |
mm | 160 |
200 |
250 |
260 |
||||||||
Ejector Tonnage |
KN | 110 |
110 |
150 |
210 |
||||||||
Ejector Number |
td> | 13 |
13 |
17 |
17 |
||||||||
OTHERS |
|||||||||||||
Max.Pump Pressure |
Mpa | 16 |
16 |
16 |
16 |
||||||||
Pump Motor Power |
KW | 37 |
37 |
55 |
60 |
||||||||
Heater Power |
KW | 24.5 |
24.5 |
36 |
37.2 |
||||||||
Machine Dim. (LxWxH) | m |
7.3x1.8x2.2x | 7.3x1.8x2.2x | 9.3x2.1x2.4 | 9.6x2.4x2.7 | ||||||||
Machine Weight |
t |
12.5 |
12.5 |
23 |
32 |
